The compact all-rounder – big in a small room
Our “smallest one” is also our latest and is packed full with innovative solutions in its construction, design, workmanship and equipment flexibility.
Whether for use in endoscopy or for outpatient treatment, wherever space conditions are cramped and working requirements are varied and flexible, this ceiling supply unit scores very highly.
The lightweight spring arm of modufilio can move the compact supply head into any position in a maximum radius of 2.2 metres around the ceiling mount.
Despite its small size the unit can be equipped with a wide range of options including high voltage and low voltage current, medical gases, data and communications technologies and storage surfaces for medical apparatus.
An LED lamp which can also be supplied in different colours provides additional work area lighting.
Key Details
Electric specifications
230 V - 240 V / 50 Hz - continuous operation
Protection class I
IP 20 degree of protection
Lighting technology LED at side (optional)
Nominal voltage: 230 V - 240 V / 50 Hz
Protection class: I
Connection cross-section: 1mm² max.
Protection type: IP 54
Lamp output: 2.5 W
Operating pressure of medical gas technology
Oxygen: 5 bar
Compressed air: 5 bar
Vacuum: - 0,8 bar
General information
Minimum opening for cable: 28 mm x 28 mm
Narrowest point (bearing): Ø = 50 mm
Spring ranges: 8 - 16 kg; 15 - 32 kg; 30 - 45 kg
Additional load in support arm: Max. 45 kg
Optional cable management
Optional console
HOT OFF THE PRESS, DIGITAL ONLY - OUR BROCHURES
modufilio – The compact all-rounder – big in a small room
Assembly, cleaning and maintenance
01. Assembly
The medical supply units and single-bed lighting fixtures can be installed and mounted on solid or plasterboard construction walls. Customer provided substructure is required for plasterboard walls. Project-specific substructures are used for ceiling-mounted supply units.
02. Cleaning
Our products can be cleaned with conventional cleaning agents and disinfected with alcohol-free disinfectants.
Surfaces are protected by high-quality electrostatic powder coating. Non-coated parts are made of anodized aluminium or chrome-nickel steel. All plastic parts are resistant to cleaning agents and disinfectants.
03. Maintenance & repair
The system must be maintained for the first time after 5 years and then after every 2 years. A contractual service agreement can be concluded for the maintenance work if required. More information can be found in the respective operating instructions.
04. Accessories
Our comprehensive range of accessories means you can set up your work area exactly as you want it. Consult our Accessories Catalogue to find out about the wide range of options available to you.
